Size: 2" ~ 24"
Rating : ANSI 600lb ~ 2500lb
Body Materials:Carbon Steel, Chromium Moly Alloy Steel (WCB, WCC, WC6, WC9, C5, C12, C12A ,etc.)
Trim: Per API 600
Operation: N/A
General Description: Pressure seal bonnet valves (PSB Valves) are designed for high temperature, high pressure, services mainly encountered in nuclear and fossil fuel power plant. Compare with bolted bonnet valves, FLOWTEK pressure seal valves are less complicated and can provide absolute excellent seal service with minimum maintenance.
Design Standard:
Basic Design: BS 1868,
API 6D, ASME B16.34
Face-Face Dimension: ASME B16.10,
End Connection: ASME B16.5, ASME B16.47, MSS SP-44, ASME B16.25
Test: API 598, BS 6755Products Range:
Size: 2" ~ 24"
Rating : ANSI 600lb ~ 2500lb
Body Materials:Carbon Steel, Chromium Moly Alloy Steel (WCB, WCC, WC6, WC9, C5, C12, C12A ,etc.)
Trim: Per API 600
Operation: N/ADesign Feature:
Stellited seating surface
Optional piston type disc with spring loaded
Absolute bonnet joint leak proof
Optional by-pass design
Optional Pneumatic operated for quick shut off within 1 secondApplication:
Refinery
Petrochemical
Power plant
General Industry
